🧪 Data Quality & Testing Strategy

Portfolio Scenario — Data Quality

⚠️ This document addresses real data quality issues found in the public Olist dataset, treated as live business risks in a simulated production environment. Every flag, test, and fix below maps to an actual anomaly in the source data.

📘 SSOT Cross-References

• Architecture & layer flow: 01_architecture.md
• Business KPI definitions: 00_business_requirements.md
• Performance benchmarks: 05_performance_optimization.md
• Engineering standards & CI setup: 06_engineering_standards.md

---

1. Quality Framework at a Glance

Core Strategy — Three principles that never bend

• Flag, don't delete — 100% of source data preserved; anomalies exposed, not hidden
• Zero-trust validation — Every layer has explicit tests before downstream consumption
• Fail fast, never silently — CI blocks merges; schema contracts catch drift at compile time

559 tests. 5 layers. 0 silent failures.

Layer	Tests	Focus	Tool
RAW	85	Freshness, row counts, PK checks	dbt sources.yml
STAGING	456	PK/FK integrity, enums, nulls	dbt generic tests
INTERMEDIATE	18	Business rules, cross-column logic	dbt singular tests (SQL)
MARTS	—	Grain enforcement, FK coverage	dbt contracts + generic
Power BI	—	Column presence, type contracts	Power Query SelectColumns

End-to-end quality pipeline:

Azure Blob → RAW            → STAGING          → INTERMEDIATE      → MARTS             → Power BI
             85 source tests   456 generic tests  18 singular tests   Schema contracts    Dual metrics
             Freshness SLA     PK/FK integrity    Business rules      Grain enforcement   Verified vs. Total
             Row counts        State enums        Flag logic          FK coverage         Trust tooltip UX

---

2. Source Data Inventory

What landed in RAW — known issues documented here, not hidden, not fixed silently.

Source Table	Rows	Format	Known Issues	Treatment
raw_orders	99,441	CSV	2,965 missing delivery dates (non-delivered orders)	Valid NULLs — status-based filter
raw_order_items	112,650	Parquet	—	Clean ✅
raw_customers	99,441	CSV	customer_unique_id not entity-unique (repeat buyers)	Dual key strategy in staging
raw_products	32,951	CSV	610 missing dimensions + 611 NULL categories	Flagged is_missing_dimensions
raw_sellers	3,095	CSV	—	Clean ✅
raw_order_payments	103,886	CSV	—	Clean ✅
raw_order_reviews	99,224	JSON	814 duplicate review_ids (repeat reviews, same order)	Flagged is_duplicate_review
raw_geolocation	1,000,163	CSV	1M+ rows → 19K unique zip centroids after dedup	Deduplicated in staging
Total	1,550,851	—	Phase 2 raw quality score: 99.998%	All anomalies flagged, none deleted

Snowflake row count verification across all 8 RAW tables after Phase 2 ingestion

---

3. Test Coverage Matrix

3.1 Test Pyramid

            ▲
           ╱ ╲
          ╱   ╲      18 Singular Tests  ← Custom SQL business-rule assertions
         ╱     ╲       • No future order dates
        ╱       ╲      • Timestamp sequence: Ordered → Approved → Shipped → Delivered
       ╱─────────╲     • Negative price / freight value checks
      ╱           ╲    • Delivered orders must have delivery_date
     ╱  456 Generic╲
    ╱   dbt Tests   ╲  ← Unit-level column contracts
   ╱   (82% total)   ╲   • `unique` + `not_null` on all 29 PKs
  ╱                   ╲  • `relationships` on all 17 FKs
 ╱─────────────────────╲ • `accepted_values` — 27 BR states, 5 order statuses
                         \
              85 Source Tests        ← Freshness & count gates at ingestion boundary
              (15% total)              • Freshness: warn 7d / error 14d
                                       • Row count reconciliation vs. Azure Blob
                                  ✅ 559 total | 100% pass rate

3.2 Singular Test Register (Business Rule Assertions)

Test File	Severity	Rule Enforced	Protects
assert_no_future_order_dates	ERROR	order_date <= CURRENT_DATE	Timeline integrity
assert_order_timestamps_logical_sequence	WARN	ordered_at ≤ approved_at ≤ shipped_at ≤ delivered_at	SLA calculation accuracy
assert_no_negative_prices_or_freight	ERROR	price >= 0 AND freight_value >= 0	Revenue calculations
assert_delivered_orders_have_delivery_date	ERROR	status = 'delivered' → delivered_at IS NOT NULL	Logistics SLA metrics
assert_retention_sequence_no_gaps	ERROR	order_sequence_number has no skipped integers	Repeat customer classification
assert_verified_flag_logic_consistent	ERROR	is_verified = FALSE only when at least one flag set	Dual metric integrity

3.3 Coverage Summary

Coverage Type	Target	Achieved	Status
Primary Keys	100%	29/29 models	✅
Foreign Keys	100%	17/17 relations	✅
Source Freshness	100%	8/8 RAW tables	✅
State Enum (BR)	100%	27/27 states	✅
Order Status Enum	100%	5/5 values	✅
Test Pass Rate	100%	559/559 tests	✅
Schema Contracts	100%	All MART models	✅

559/559 tests passing — dbt build output showing full test suite green across all layers

---

4. Known Issues → Fix → Impact

Issue 1: Finance Can't Reconcile Revenue

Root Cause: 3 departments each had a different "Revenue" definition. Deleting anomalous rows makes Finance ERP reconciliation impossible — the numbers never match.

Fix: "Flag, Don't Delete" — add is_verified master flag in int_sales__order_items_joined. Expose dual metrics in Power BI side by side.

Numbers:

Total Revenue:     R$ 13,591,643  ← matches Finance ERP exactly (100%)
Verified Revenue:  R$ 13,564,851  ← executive reporting (99.8%)
Revenue at Risk:   R$ 26,792      ← flagged anomalies, visible to Finance (0.2%)

Before → After: 4 days/month manual reconciliation → 0 hours (automated dual-metric match).

UAT sign-off: Total Revenue matches Finance ERP; Verified Revenue confirmed separately for exec reporting

---

Issue 2: Schema Changes Break Dashboards Silently

Root Cause: Power BI refreshes succeeded even after dbt column renames. Visuals showed blank data — detected by business users 2 days later, not by the system.

Fix:

• dbt side: contract: enforced: true in all MART models — CI fails immediately on column drift
• Power BI side: Table.SelectColumns() in Power Query — refresh errors on any missing column

Before → After: 2-day silent failure → < 5 minute CI detection.

dbt schema contracts enforced at compile time — breaking column changes fail before hitting Snowflake

Power BI explicit column selection — refresh fails fast on any schema mismatch

---

Issue 3: Timestamp Violations Corrupt SLA Metrics

Root Cause: 127 orders have delivered_at < ordered_at — physically impossible. The "Days to Deliver" SLA metric was returning negative values, destroying Operations' confidence in the dashboard.

Fix: Singular test assert_order_timestamps_logical_sequence blocks future violations. has_timestamp_violation flag isolates the 127 rows. All SLA measures filter on is_verified = TRUE.

Before → After: Negative SLA values polluting Operations reports → 99.8% clean metrics, 127 rows isolated and auditable.

---

Issue 4: Duplicate Customer IDs Break Retention Analysis

Root Cause: Olist generates a new customer_id per order — the same buyer has dozens of IDs. 0% of repeat buyers are identifiable without resolving this identity fragmentation.

Fix: Dual key strategy in staging. user_sk = hash(customer_unique_id) is the persistent person key. int_customers__prep deduplicates via ROW_NUMBER() OVER (PARTITION BY user_sk ORDER BY source_loaded_at DESC). order_sequence_number = 1 → New customer; >= 2 → Repeat.

Before → After: 0% identifiable repeat buyers → full retention cohort analysis across all 100K+ orders.

---

Issue 5: 610 Products Missing English Category

Root Cause: Olist category names are Portuguese-only. 610 products have no category at all. International BI reporting breaks with blanks or errors.

Fix: int_products__enriched applies a 3-tier fallback: COALESCE(english_name, portuguese_name, 'Unknown'). Zero data loss — all 32,951 products present in marts.

Before → After: Blank/broken category filters → 100% category coverage in product dimension.

---

5. Quality Flag Implementation

Where: int_sales__order_items_joined.sql (INTERMEDIATE layer — business logic defined once, reused by all downstream marts and Power BI measures)

Flag Column	Trigger Condition	Row Count	% of Total
has_missing_product	product_id IS NULL	610	0.6%
has_invalid_price	order_total <= 0 OR freight_value < 0	235	0.2%
has_timestamp_violation	delivered_at < ordered_at	127	0.1%
has_duplicate_review	Duplicate review_id per order	814	0.8%
is_verified	TRUE only when ALL four flags above are FALSE	98.9%	✅ Master switch

SQL Implementation:

-- int_sales__order_items_joined.sql (simplified)
case
    when product_id is null                          then false
    when order_total <= 0 or freight_value_brl < 0  then false
    when delivered_at < ordered_at                   then false
    else true
end                                                  as is_verified,

case
    when product_id is null        then 'Missing Product'
    when order_total <= 0          then 'Invalid Price'
    when delivered_at < ordered_at then 'Arrival Before Approval'
    else null
end                                                  as quality_issue_reason

DAX Consumption in Power BI:

-- Finance reconciliation — always matches ERP
Total Revenue = SUM(fct_order_items[order_total_brl])

-- Executive reporting — clean data only
Verified Revenue =
CALCULATE(
    SUM(fct_order_items[order_total_brl]),
    fct_order_items[is_verified] = TRUE
)

-- Risk transparency — never hidden
Revenue at Risk = [Total Revenue] - [Verified Revenue]

Trust tooltip — hover reveals Verified %, Revenue at Risk $, and quality reason per data point

Dedicated audit view — every flagged row visible to Finance for investigation

---

6. CI Quality Gate

Mechanism: GitHub Actions blocks PR merge on any test failure. No untested code reaches production.

Two-Stage Pipeline:

Stage 1 — Push to feat/**                     Stage 2 — PR to main
──────────────────────────────────────────    ──────────────────────────────────────────────
SQLFluff lint (syntax check)                  dbt build --target ci --full-refresh
dbt parse (no Snowflake connection)           559 tests run against ephemeral CI_PR_<n> schema
~45 seconds                                   Auto-dropped post-merge (no shared state)
Fast feedback before PR opened               ~8–12 min production-equivalent validation

Enforcement Controls:

Control	Implementation	Effect
Merge block on failure	GitHub branch protection on main	0% untested code in production
Isolated CI schema	CI_PR_<number> in OLIST_DEV_DB	No shared state between concurrent PRs
Auto schema cleanup	drop_ci_schema macro post-merge	Zero schema accumulation in dev
< 5 min Stage 1 feedback	Parse + lint only (no DB call)	Fast iteration before opening a PR
Auto GitHub Issue on fail	Workflow creates issue automatically	Zero manual triage of CI failures

GitHub Actions: Full dbt build passing across all 559 tests in ephemeral CI schema

PR merge gate — all checks must be green before merge is permitted

Stage 1 SQLFluff lint — zero violations required before PR creation

---

7. Monitoring & Freshness

7.1 Source Freshness SLA

Configured per-source in _sources.yml with tiered thresholds — critical sources monitored more tightly.

Source	Warn After	Error After	Rationale
raw_orders	1 day	2 days	Core revenue path — highest priority
raw_order_items	1 day	2 days	Fact grain source
raw_customers	7 days	14 days	Slower-changing dimension
raw_products	7 days	14 days	Catalog updated infrequently
raw_sellers	7 days	14 days	Stable master data
raw_order_payments	1 day	2 days	Financial data — tightly monitored
raw_order_reviews	7 days	30 days	Non-critical enrichment
raw_geolocation	30 days	90 days	Static reference — rarely changes

Production Status: ✅ 8/8 tables within SLA · ✅ < 1 hour ingestion latency · ✅ 0 stale incidents (30 days)

7.2 Dual-Clock Freshness in Power BI

Problem: Business users distrust data without knowing when it was last updated — a single timestamp doesn't tell the full story.

Solution: Two independent clocks on every dashboard footer.

Clock	Source Column	What It Shows
Last Refreshed	_dbt_updated_at	When dbt last transformed the marts data
Data Current Until	_source_loaded_at	When the source file last landed in RAW

The gap between them surfaces pipeline lag — visible to every consumer without a support ticket.

Last Refreshed =
"Model refreshed: " & FORMAT(MAX(fct_order_items[_dbt_updated_at]), "DD MMM YYYY @ HH:MM")

Data Current Until =
"Source data as of: " & FORMAT(MAX(fct_order_items[_source_loaded_at]), "DD MMM YYYY @ HH:MM")

Dashboard footer — dual timestamps on every page give users full freshness transparency

---

8. Evidence Index

Evidence	Screenshot	What It Proves
559 tests passing		Full dbt build green across all layers
dbt schema contracts		Compile-time column/type enforcement on MART models
CI pipeline pass		GitHub Actions dbt build full-refresh in CI schema
PR merge gate		Branch protection blocking merge on test failure
SQLFluff clean		Zero SQL lint violations pre-commit
Revenue reconciliation		Total Revenue matches Finance ERP; Verified split confirmed
Trust tooltip UX		Quality reason exposed per data point in Power BI
Data quality audit view		All flagged rows visible for Finance investigation
Power BI schema contract		Explicit column selection — fails fast on schema drift
Source row counts		1.55M rows validated across 8 RAW tables
BPA — 0 issues		Tabular Editor Best Practice Analyzer: 0 violations
End-to-end lineage		Full dbt DAG: RAW → STAGING → INTERMEDIATE → MARTS

---

9. Measured Impact

9.1 Quality Scorecard

Metric	Result	Target	Status
Total Tests	559	—	✅
Test Pass Rate	100% (559/559)	100%	✅
Primary Key Coverage	100% (29/29 models)	100%	✅
Foreign Key Coverage	100% (17/17 relations)	100%	✅
Source Freshness	8/8 within SLA	100%	✅
Verified Revenue	R$ 13,564,851 (99.8%)	> 99%	✅
Revenue at Risk	R$ 26,792 (0.2%)	< 1%	✅
CI Stage 1 Feedback	~45 seconds	< 5 min	✅
CI Full Build	~8–12 min	< 15 min	✅
Dashboard Load Time	1.8s (95th percentile)	< 2s	✅
Schema Contract Models	100% of MART models	100%	✅

9.2 Operational Impact

Process	Before	After	Improvement
Finance Reconciliation	4 days/month (manual)	0 hours	100% automated
Schema Break Detection	2-day user discovery	< 5 min CI failure	99.7% faster
DQ Issue Triage	6 hours/week	2 hours/week	67% reduction
Ad-hoc Revenue Requests	12 hours/week (analyst)	Self-service	~40 hrs/week saved
Untested Code in Prod	Possible (no gate)	0% (CI blocked)	Zero incidents

Total analyst time recovered: ~112 hours/month from automated quality enforcement replacing manual processes.

---

10. Key Principles

Five principles this framework never violates

1. Flag, Don't Delete — 100% source data preserved; Finance reconciliation always possible regardless of anomalies
2. Explicit Over Implicit — Schema contracts fail at compile time, not at user discovery time two days later
3. Trust Through Transparency — Dual metrics exposed side by side; stakeholders see both clean and at-risk numbers
4. Zero-Trust by Layer — Every layer earns its own gate; downstream trust is never inherited from upstream
5. Fail Fast, Fix Early — < 5 min CI feedback loop; broken code never reaches a stakeholder dashboard

---

Quality is not a feature. It's the contract between the data team and the business.

Every row is accounted for. Every metric has a quality score. Every change is tested before it ships.
